Three-bladed, Counter-rotating discs

With three blades per disc, Kubota mowers provide a 50% higher cutting frequency compared to conventional solutions. This means a third less load per blade, an even load on the drive, smoother power usage, and produces a neat, cleanly cut stubble.

Fully welded cutterbar

The Kubota cutterbar’s high cooling and lubrication efficiency oil pump system reduces wear and tear. The fully welded cutterbar with overlapping C-channels makes for a very strong design.

Shear Protection

Shear protection of gear wheels and the drive system designed to break in case or overload or major contact. Once sheared, the hub is easily replaceable for minimum downtime.

Independent Active Suspension

The complete mowing section, is suspended independently from the main chassis by either two or four long adjustable suspension springs, allowing field tracks and contours to be closely followed. If an obstacle is encountered in the field, the mowing section will lift up and backwards, protecting the cutterbar.

Easy adjustment of stubble height

A simple crank adjusts the whole cutterbar assembly angle up or down to a desired stubble height. While standard with 40mm skid shoes, additional 20mm, 60mm or 80mm are available to further adjust cutting height.

Full-width Semi Swing Tine Conditioning

The Kubota SemiSwing tine conditioner with adjustable conditioning hood is highly adaptable to varying crop types. During operation tines will stay in a fixed position, providing full cutterbar width conditioning with minimum wear.

Full-width Rubber Roller Conditioning

Roller conditioning provides gentle, yet effective handling of fragile crop such as alfalfa or clover. The adjustable spring-controlled pressure exerted between the two rollers guarantees uniform conditioning and low risk of plugging.
